Juiced U500 (V3) Utility Electric Bicycle
The U500 is designed from...
The U500 is designed from the ground up to be the ultimate car-replacement electric bicycle.
Every part has been carefully designed with performance, reliability, practicality and serviceability in mind. Rather than installing poorly performing off-the-shelf electric drive kits, Juiced invested 5 years developing their own electrical systems that go far beyond the limitations of standard e-bike technology. The Juiced custom battery pack and specially tuned electronics are integrated perfectly to create the ultimate car replacement E-bike.
The aluminum low-step cargo frame is the core of the U500 utility platform. Juiced worked hard to retain 100% conformity to bicycle standards thus the mechanical parts can be serviced at any bicycle shop. The Juiced precision electrical components are modular and very easy to service.
Geometry
SHIPS: FEB 2017
Specifications
-
FRAME
Extruded Rust-free Aluminum Frame -
DRIVE UNIT
Bafang (8Fun) 350W / Geared hub motor / Shimano cassette -
DISPLAY
King Meter T320 / Customized 4-button / 5 Levels assist: ECO, 1, 2, 3 and SPORT (24 mph) -
BATTERY
48V x 7.8 Ah Samsung 18650 / 39 cells x 2,600 mAh / Standard Battery
-
SHIFTING SYSTEM
Shimano Alivio -
TRANSMISSION
Shimano Alivio 11-32t -
REAR SPROCKET
Shimano Alivio 9 speed 11-32T -
CHAIN WHEEL
Pro Wheel 52T -
FRONT BRAKE
Shimano BR-M375 Mechanical Disc Brakes -
REAR BRAKE
Shimano BR-M375 Mechanical Disc Brakes -
TIRES
Kenda Small Block 8 -
WHEELS
26" Double-Wall / 36H -
SPOKES
Stainless / Front: 13G / Rear: 12G -
HANDLEBAR
Cruiser wide / Quill Stem -
SADDLE
Velo comfort wide -
SEAT POST & SADDLE
Promax 27.2 mm / Quick release -
PEDALS
Welgo Comfort platform pedals -
WEIGHT
46LBS -
WHEEL SIZE
26"
